Modulo2 ME

Slurry Tanker

Litreage from 2.490L - 11.416L

The MODULO2 is available as single axle with a capacity from 2,500 to 11,000 l and as double-axle from 8,400 to 18,000 l.

The tank is laid down on and welded on an integral cradle (on its width and length) on which the traction strains are focused.

The double-axle MODULO2 is fitted with a bogie running gear.

Modulo2 MEB

Slurry Tanker

Literage from 8.590L - 18.229L

The MODULO2 is available as single axle with a capacity from 2,500 to 11,000 l and as double-axle from 8,400 to 18,000 l.

The tank is laid down on and welded on an integral cradle (on its width and length) on which the traction strains are focused.

The double-axle MODULO2 is fitted with a bogie running gear.

Komfort2

Slurry Tanker

Literage from 8.590L - 18.229L

The KOMFORT2 is fitted with an independent chassis and a cross-spring hitching suspension protecting the tank from all strains.

Volumetra

Slurry Tanker

Literage from 14.800L - 20.500L

Volumetra: its name says it all. This vehicle is specially designed to be efficiently fitted with volumetric pumps while limiting the overall dimensions. It is however very well suited to vacuum pumps.

Quadra

Slurry Tanker

Literage from 14.652L - 20.110L

The Quadra is a double-axle vehicle that is perfectly suited for intensive slurry spreading and transport works. The chassis is standard fitted with integrated anchoring points, in order to easily mount a possible linkage.

The QUADRA is also standard fitted with a Hydro-Tandem running gear ensuring an optimal driving stability as well as an unmatched driving comfort.

X-Trem

Slurry Tanker

Literage from 12.485L - 20.390L

The X-TREM slurry spreader is the ideal vehicle for contractors who wish a machine with a small length, a large tank diameter and tyres up to Ø 1.82 m (e.g. 800/65R32). The chassis, which is 760 mm wide at the level of the running gear, allows to fit wide wheels (≤ 850 mm), without reducing the large steering angle of the rear axle.

Hydropneumatic drawbar, self steering system, Hydro-Tandem and pre-equipment for wide boom are only a part of the equipment that makes of this tanker the ideal tool for the most arduous works.

Euroliner

Slurry Tanker

Literage from 16.580L - 28.000L

The independent supporting structure is made up of a Universal chassis (300 x 100 x 10 mm) leaning against the tank.

The EUROLINER is designed to be practical both on roads and in the fields. In this respect, this vehicle has an extensive standard equipment aiming at a high safety and driving comfort level, like a double forced steering axle that provides an outstanding driveability and a surprising agility in the field.

Q-Bigliner

Slurry Tanker

Literage from 28.600L - 31.800L

For the Q-BIGLINER, JOSKIN decided to mount tanks with a diameter of 2,300 mm on an EUROLINER chassis. Its large volume is in this way made very compact, which allows an easy manoeuvrability.

These vehicles are designed for intensive transport on roads and in the fields, and are therefore not fitted with a pre-equipment for injectors or spreading booms.

Siroko

Muck Spreader

9-13 Tonne

The JOSKIN Siroko spreader with lowered galvanized body is remarkable in many ways: its innovative design makes maintenance much easier. The cross-suspension hitching and the large dimensions of the wheels provide it with an excellent stability both when working and on the road. Its body in HLE 550 high tensile steel is made up of successive foldings and has a rectangular upper strip. The side walls of 850 mm, 1,090 mm, or 1,340 mm high offer a load capacity from 5 m³ to 14.17 m³. According to the product, the two beaters with folded spirals split and spread from 7 to 10 m away per row.

Ferti-Cap

Muck Spreader

8-12 Tonne

The new JOSKIN Ferti-CAP with wide monocoque body in HLE 550 steel of 810 mm high spreads on a wide surface. With its capacities from 6.91 to 13.97 m³, it is very multi-functional in spreading and transport of various materials. According to the product, the large diameter of the vertical beaters with folded spirals allow to spread on a width from 8 to 12 m per row.

The beaters can easily be removed to convert the Ferti-CAP into a harvest trailer (silage and others).

Tornado3

Muck Spreader

12-15 Tonne

The Tornado3 is also a muck spreader with lowered narrow body in HLE steel and wheels with a large diameter as well. Its high capacities and sturdiness are ensured by its body made up of successive folds and by a side reinforcing post.

This body with a height of, 1,130 mm to 1,570 mm (offers load volumes from 8,6 to 25,8 m³ according to the model. The beaters with folded spirals spread evenly on a width from 7 to 16 m per row, depending on the product.

Tornado3 Horizon

Muck Spreader

13-15 Tonne

The Horizon swinging scatterer l is made up of two horizontal beaters with Ø 600 mm of diameter (rotation: 300 rpm) and with two spreading discs with 1.100 mm diameter (rotation: 425 speed rpm).

The ovoid shape and the entangling of the spreading discs allow their integration in 1.100 mm on a narrow body. This large diameter and their perfect synchronization with the horizontal beaters allow a wide and homogeneous spreading.

The inside of the canopy is padded to prevent the matter to agglomerate against the rear wall.
