Hit

Mounted 4/6/8 Rotor Tedders.

Working Widths from 5.4m-8.86m

Download Brochure Enquire Now

Product Enquiry: Hit

  • This field is for validation purposes and should be left unchanged.
Categories: , Brand:

Features

  • Pivoting Headstock for smooth cornering
  • Hydro comfort Hydraulic lifting of outer rotors
  • Heavy Duty Tine security system
  • asymmetric Tines
  • Overload protection Clutch
  • Dual shock absorber struts ensures machine remains centred on slops
  • Tine arm support discs ensure tine arms cannot twist
  • High quality powder coated paint finish

Specifications

HIT 4.54 HIT 6.61 HIT 6.69 HIT 6.80 HIT 8.81 HIT 8.91
Width 5.40 m 6.0 m 6.85 m 7.85 m 7.81 m 8.86 m
Working width DIN 5.20 m 5.75 m 6.45 m 7.45 m 7.70 m 8.60 m
Rotors 4 6 6 6 8 8
Rotor diameter 1.67 m 1.30 m 1.42 m 1.67 m 1.30 m 1.42 m
Tine arms per rotor 6 5 6 6 5 6
Transport width 2.85 m 2.55 m 3.0 m 3.0 m 2.94 m 3.0 m
Parking height 2.60 m 2.97 m 3.35 m 3.73 m 2.87 m 3.26 m
Hydraulic connections 1 S 1 S 1 S 1 S 1 D 1 D
Weight 550 kg 785 kg 855 kg 940 kg 1090 kg 1250 kg
