Tine Harrow Air Seeder Combo

Standard Model – 8mm Tines

Enquire Now

Product Enquiry: Tine Harrow Air Seeder Combo

Name(Required)
This field is for validation purposes and should be left unchanged.

Features

6M Versatile Harrow with Air Seeder for pasture renovation, Weeding, Light Cultivation, Crop sowing and Soil aeration

  • 3 Pt Linkage Mounted with Loading Access Platform (Standard)
  • Hydraulic Fold with Automatic Transport Locking Device
  • 8mm x 450mm Long spring Tines with Central Tine Angle Adjustment
  • Flexible Tine Harrow sections for superior Ground Hugging
  • Powder Coated Paint Finish
  • Two Seed Dosage rollers (Standard) Driven by Cog Belts & pulleys
  • 0.8 Kg up to 400 Kg per Hectare possible (Depends on seed and width)
  • Other Seed Dosage rollers available as extra for other application rates
  • Seed Agitator fitted Standard
  • Twin 12 Volt Electric Blower Fans (Standard on AIR 8)
  • Optional Hydraulic Blower Fan AIR 8
  • Flexible Direct Drive Cable to Vari -Speed Gearbox standard on AIR 8
  • Electric Sensor Drive wheel with full programmable seed rate
  • Controller (Standard AIR 16) (Option on AIR 8)

OPTIONS

  • Extra support wheels for outer wing units
  • Radar in lieu of drive wheel and sensor

Specifications

MODEL No.SEEDER OUTLETS HOPPER CAPACITY FAN DRIVE TYPE WORKING WIDTH
6m Harrow + Air 8 – Direct 8 400Ltr Hydraulic Fan 6m
6m Harrow + Air 8 – Electric 8 400Ltr Hydraulic Fan 6m
6m Harrow + Air16 – Electric 16 400Ltr Hydraulic Fan 6m
