Fodder Beet Cultivator

Ideally suited to fodder beet cultivars

Enquire Now

Product Enquiry: Fodder Beet Cultivator

  • This field is for validation purposes and should be left unchanged.

Features

Rear or front/rear mounted models available.

fitted standard with rubber or steel flanged stabilizer wheels, parallelogram row units fitted with individual farm flex rubber wheels for uniform ground contouring.

Fitted with side plant protection plates, height adjustable, spring vibration spring tine with 150mm wide duck foot shares (wider available)

  • Hydraulic power steering from drivers seat
  • Camera assist automatic steering
  • 150mm/200mm/250mm duck foot shares
  • 470mm Diameter plant protection disc’s instead of plates
  • Rear fingers STAR WHEELS for gentle inter-plant weeding
  • Parking stands

Specifications

ROWS FRAME (MAIN) WEIGHT (KG) approx* H.P TRANSPORT WIDTH
4 Fixed 364 40 2.25
5 Fixed 410 40 2.70
6 Fixed 460 60 3.15
7 Fixed 510 60 3.60
9 Hydraulic Foldable 780 60 3.00
12 Hydraulic Foldable 810 75 3.00
18 Hydraulic Foldable 1400 120 3.00
24 Hydraulic Foldable 1900 150 3.00
