L-Line Range

Spreading Widths from 10-18m*

Download Brochure Enquire Now

Product Enquiry: L-Line Range

  • This field is for validation purposes and should be left unchanged.

Category: Brand:

Features

10-24m* Working Widths

500 – 2050L* Hopper Litre capacity

1.25 Hopper Widths – per section (L15)

2.1m Hopper Widths – per section (L20)

  • To border headland spreading – easy one-step lever engage/disengage
  • P.T.O shaft with overload clutch
  • Stainless Steel Discs, Hopper bottom, Nuts, Bolts and components
  • Long-life wear-resistant Manganese Steel Vanes
  • Quad Overlap (In – Centre spreading system) – the most accurate!
  • Powder Coated “Flexi-Coat” paint finish
  • Options of Hydraulic shutter control or “ICON” Variable rate controller

(*) Spreading width and Hopper capacity can vary due to fertiliser

Specifications

MODEL *HOPPER CAPACITY VANES FITTED *SPREAD WIDTH OPTIONS (STD)
L15 Base 500 L A3-T 10-18m
L15 Base 775 L A3-T 10-18m
L15 Base 1050 L A3-T 10-18m
L15 Base 1325 L A3-T 10-18m
L20 Plus 700 L A2 12-24m Cleaning Ports. Safety Guards
L20 Plus 1150 L A2 12-24m Cleaning Ports.

Safety Guards

L20 Plus 1425 L A2 12-24m Cleaning Ports. Safety Guards
L20 Plus 1600 L A2 12-24m Cleaning Ports. Safety Guards
L20 Plus 2050 L A2 12-24m Cleaning Ports. Safety Guards
L20W Plus 2050 L A2 12-24m Cleaning Ports. Safety Guards.

Weight scales
