DK

The ROTODENT DKS is a professional folding power harrow thanks to its TWIN-FORCE tine support with tapered roller bearings is particularly suited in combination with seed drills.

300HP

Download Brochure Enquire Now

Product Enquiry: DK

  • This field is for validation purposes and should be left unchanged.
Categories: , Brand:

Features

  • 1000 rpm gearbox, rotor shaft rotation Z=30/24 (359 g./m.)
  • Linkage cat. 3, oscillating
  • Movable side plates
  • Levelling board on roller. Independently adjustable
  • Central track eraser
  • Central track eraser 1″3/8 Z=21
  • Lateral drive shafts with shear bolt or automatic cam clutch (NOT PROVIDED AS STANDARD)
  • Rear light boards

OPTIONS

  • Track eraser pair
  • NO-STOP Track eraser pair
  • Hydraulic depth adjustment
  • Hydraulic carrier for mounting a seed drill
  • Rear P.t.o.
  • Drop forged tines
  • Kit for quick release of forged tine
  • Cage roller
  • Spike roller
  • Spiral roller
  • Packer roller
  • Rubber roller

Specifications

Model HP mm. mm. mm. (n°) (n°) Kg
Rotodent DKS-400 130-330 4000 2500 280 16 16+16 2160
Rotodent DKS-450 140-330 4500 2500 280 18 18+18 2250
Rotodent DKS-500 150-330 5000 2500 280 20 20+20 2410
Rotodent DKS-600 180-330 6000 2500 280 24 24+24 2630
